STERIBLOC V-series

STERIBLOC V-series

Vertical flow air treatment unit

Healthcare establishments • Industries and research

Our units enable :

  • regulation and control

    of air pressure

  • regulation and control

    of air temperature and humidity

  • complete air treatment

    of a clean room by a complex filtration system

  • Flow from 1000 m3/h to 20000 m3/h

  • Available static pressure from 50 to 1200 Pa

  • Three operating modes

    Fresh air + recycling,All fresh air All recycling

Download the brochure

Nominal flow Air flow range Coolling capacity Heating capacity Sizes
Width x Length x Height (mm)		 Weight (Kg)
1000
 1100 m3/h 700 to 1500 m3/h 12 Kwatts 13 Kwatts 1430 x 630 x 1960 320
2000
 2100 m3/h 1500 to 2700 m3/h 22 Kwatts 24 Kwatts 1430 x 840 x 1960 370
4000
 3500 m3/h 2700 to 4250 m3/h 36 Kwatts 41 Kwatts 1560 x 970 x 1960 420
6000
 5700 m3/h 4250 to 7000 m3/h 60 Kwatts 67 Kwatts 2020 x 970 x 1960 560
8000
 7000 m3/h 6500 to 8500 m3/h 72 Kwatts 82 Kwatts 2020 x 970 x 1960 590
10000
 9500 m3/h 8000 to 10000 m3/h 98 Kwatts 111 Kwatts 2820 x 970 x 1960 650
12000
 11000 m3/h 10000 to 14000 m3/h 115 Kwatts 129 Kwatts 3030 x 970 x 1960 780
16000
 14000 m3/h 13000 to 17000 m3/h 144 Kwatts 164 Kwatts 3870 x 970 x 1960 1010
24000
 22000 m3/h 16000 to 28000 m3/h 230 Kwatts 258 Kwatts 5470 x 970 x 1960 1370

Calculation basis for air treatment units:
Nominal air flow – 100 % fresh air – fresh air summer : 32°C – 40% – Cold battery output : 11°C – 99% – fresh air winter – : -7°C – 90% – Hot battery output : 28°C

Dimensions and weight :
The width corresponds to the treatment unit with a small electrical module (210 mm must be added with a large electrical module), weight indications are averages over different selections

The characteristics indicated in this table are given for information only and may vary according to customer demand.

THE FEATURES THAT MAKE THE DIFFERENCE
COMPLIANT WITH STANDARDS REQUIREMENTS : EN 1886 / NF S 90-351 / EN 13053 +A1 / BPF / ISO 14644

  • ALUMINUM PROFILE frame, with rupture of the THERMAL BRIDGE

  • Double skin paneling with cast joints,

    exterior in painted sheet steel and tstainless steel inner sheet with compression closure.

  • Very advanced thermal and sound insulation,

    panel thickness 42mm with Rockwool insulation of 90kg/m3 density guaranteeing the absence of external condensation and excellent acoustic comfort. Fire classification A1 – incombustible EN 13 501 -1

  • Centrifugal fan, EC motor with external rotor direct coupling,

    ensuring high efficiency and no pollution due to belt wear.

  • Constant air flow control based on filter clogging

  • Switching duration between cold exchanger or evaporator 2,5 m/s top

  • Stainless steel condensate and water collection pan (consistent with the recommendations of the standard NF S 90-351) April 2013

  • Des pressions statiques disponibles de 50 à 1200 Pa

    to fight pressure dropsin aeraulic networks andabsolute filtration units

  • Three operating modes:

    fresh air + recirculated air, all fresh air or all recirculated air.

  • Adjustment of fresh or extract air flow rates

    to obtain the desired pressure level in the premises

  • Advanced air filtration,

    with three-stages, suitable for the required dust class

  • Precise integrated temperature regulation whatever the external conditions:

    • Cooling mode: the cooling capacity isobtained by a direct expansion condensing unitor by a chilled water network
    • Heating regime: the calorific poweris obtained by electric resistancesor by a hot water network

  • Efficient regulation of relative humidity:

    • Dehumidification by condensation ona cold battery
    • Optional steam generator humidificationoptional
